SmarDen Smart MCB 2 Pole 63A

Product Description

Technical Specifications of Smart MCB are as follows:

• Load Capacity: 63A
• Poles: 2 Poles and Single-phase MCB
• Communication: Wifi Based
• Communication Module: WiFi Module
• Works with: Mobile app or Cloud Platform
• Device Security: 128-bit AES encryption in Payload
• Phase line leakage current: steady-state current consumed per phase line 0.2mA
• Operating temperature: -25 C ~ +65 C
• Operating distance from Wi-Fi router: up to 30 meters* (depending upon router and its placement)
• Rated Operational Voltage: 415 V(2P/3P/3P+N/4P)
• Rated Frequency: 50/60 Hz for AC
• Service Short circuit capacity: 6KA
• Rated Short Circuit capacity: 6KA
• Rated insulation voltage: 500 V
• Rated impulse withstand voltage: 4KV
• Degree of protection: IP20
• Protection level: IP20
• Suitability of Isolation: YES
• Dimensions: Three Phase (4 Pole) 89x95x72 mm
• Communication Wi-Fi:  Connects to 2.4 GHz, Wi-Fi 802.11 b/g/n
• Frequency (MHz): 865-868MHz
• Gain: 1 dBi
• Impedance (): 50
• Connector: SMA- plug right angle
• VSWR :< 2.0
• Antenna Housing: Aluminum-commercial Grade
• Polarization: vertical
• Manual operations: Supported

Features:

Works Remotely: The device works remotely with the SmarDen Mobile application and it can be controlled from anywhere in the world. The User can control all the nodes individually from anywhere.

Scheduling: The user can schedule any individual load connected to the devices i.e. Lights, bulbs, fans, etc. to turn on/off at a specific time. Once the schedule is set the device will follow the instructions at that specific time. The user can also repeat the schedules to make it work throughout the week and at any point in time.

Routines: The User can also create a Routine depending on the requirements. In a particular routine, the user can set multiple appliances to turn on/off at a specific time of the day. Once the routine is set the devices will attain their state at that point in time. For eg. I can create a routine to turn on the Fan and turn off the lights in my room at 9 AM in the morning.

Auto-off timer: The user can also set auto-off timers for a specific appliance to turn off after a particular time. For eg. I can set the auto-off timer to turn off the lights in 50 mins.

History: The user can also check the history of any individual appliance, the history report will tell the user about the switching details of that particular appliance. In the history details, the user will get to know about the time at which the appliance is turned on/off and it will also tell WHO controlled the appliance. For eg. If I manually turned on the light at 9 AM, then in the history it will be updated as a manual off Action has been taken on lights at  9 AM, or if any of my family members controlled the device from the mobile app, Ill get to know who controlled the device and at what time the action has been taken.
